F2H-ODU-P16 Series ODF
F2H-ODU-P16 Series ODF is used as terminal equipment of fiber optic cable for optical fiber wiring, fixation, fusion and patching.
DATASHEET
SOFTWARE
MANUAL
CERTIFICATE
1.Changeable adapter panel for SC, FC, LC, etc.
2.Cable fixation and strength member fixation system on the left and right back of ODF.
3.Excellent fiber bending radius mechanism to ensure minimum bending radius.
4.Very reasonable cable management.
5.Removable door and cover.
6.Drawer type ODF.
7.High density ODF.
